Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Flex Stack, DWM | |
| IC Encapsulation Type | TubeTube | |
| Availability Status | Active | |
| Switch Position Options | 60 | |
| Component Spacing Distance | 0.050" (1.27mm) | |
| Grid Row Count | 2 | |
| Row Pin Gap | 0.100" (2.54mm) | |
| Complete Pin Dimension | 1.050" (26.670mm) | |
| Mating Post Length | 0.162" (4.115mm) | |
| Stacked Assembly Height | 0.768" (19.507mm) | |
| Solder Tail Extension | 0.120" (3.048mm) | |
| Attachment Mounting Style | Through Hole | |
| Circuit End Method | Solder | |
| Mating Post Pin Finish | Gold | |
| Mating Post Coating Thickness | 10.0µin (0.25µm) | |
| Visual Hue | Black |
Description
Available in a color identified as Black to enhance system aesthetics. Showcases mating post finish evaluated at Gold. Offers mating post finish thickness of 10.0µin (0.25µm). Total pin length 1.050" (26.670mm) to ensure accurate insertion. Length of the post 0.162" (4.115mm) for reliable connection. Height of the stack 0.768" (19.507mm) for effective component layering. Length of the tail 0.120" (3.048mm) to provide mechanical clearance. Mounting style Through Hole for structural integrity. Total positions 60 for switches or mechanical elements. Total rows 2 for matrix or display setup. Enclosure TubeTube for component protection or transport. Spacing 0.050" (1.27mm) for component arrangement or connector alignment. Product condition Active for availability and lifecycle. Row distance 0.100" (2.54mm) for connectors or PCB arrangement. Product or component classification series Flex Stack, DWM. Termination method Solder for electrical or mechanical linkage.
