97-3106A-16S-1P
Data Sheet
Attribute
Description
Manufacturer Part Number
97-3106A-16S-1P
Manufacturer
Description
MIL-DTL-5015 (MS3100-MS3108) Circular Connectors
Manufacturer Lead Time
10 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Interface Connector Category | Plug, Male Pins | |
| Switch Position Options | 7 | |
| Insert Shell Dimension | 16S-1 | |
| Military Shell Standard | - | |
| Attachment Mounting Style | Free Hanging (In-Line) | |
| Circuit End Method | Solder Cup | |
| Secure Attachment Method | Threaded | |
| Installation Orientation | N (Normal) | |
| Dust Water Resistance Rating | - | |
| Housing Material and Surface | Aluminum, Olive Drab Cadmium Plated | |
| Pin Surface Treatment | Silver |
Description
Measures resistance at forward current Plug, Male Pins for LED or diode evaluation. Incorporates a connector type labeled as Plug, Male Pins. Includes contact finish plated at Silver to enhance conductivity. Employs fastening type identified as Threaded. Mounting style Free Hanging (In-Line) for structural integrity. Total positions 7 for switches or mechanical elements. Positioning N (Normal) for correct installation or signal alignment. Material and finish of shell Aluminum, Olive Drab Cadmium Plated for resilience. Insert shell dimension 16S-1 for connector compatibility. Termination method Solder Cup for electrical or mechanical linkage.
