TBJA106K010LRSB0023
Data Sheet
Attribute
Description
Manufacturer Part Number
TBJA106K010LRSB0023
Manufacturer
Description
TBJ Series 10 µF 10 V 10% Surface Mount Tantalum Capacitor
Manufacturer Lead Time
16 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Storage Capacity Electrical | 10uF | |
| Rated Operating Voltage | 10V | |
| Accuracy Tolerance Percentage | ±10% | |
| Series Resistance Equivalent | 1.8 Ohm | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 1206 (3216 Metric) | |
| Package Size Specs | 0.126" L x 0.063" W (3.20mm x 1.60mm) | |
| Maximum Mounted Height | 0.071" (1.80mm) |
Description
Offers a capacitance level rated at 10uF to ensure circuit stability. Offers ESR rated at 1.8 Ohm. Maximum seated height of 0.071" (1.80mm) for components mounted on the board. Mounting style Surface Mount for structural integrity. Operating temperature -55°C ~ 125°C for thermal stability. Enclosure/case 1206 (3216 Metric) providing mechanical and thermal shielding. Dimensions 0.126" L x 0.063" W (3.20mm x 1.60mm) for mechanical or electrical components. Dimension measurement 0.126" L x 0.063" W (3.20mm x 1.60mm) for component details. Tolerance ±10% for precision in manufacturing. Peak Vce(on) at Vge 10uF for transistor parameters. Operating voltage rating 10V for device specifications.
