Attribute
Description
Manufacturer Part Number
V5236B-T
Manufacturer
Description
HEATSINK ALUM ANOD
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Device Type Classification | Board Level | |
| Thermal Package Design | SOT-32, TO-220 | |
| Mounting Technique | Bolt On | |
| Physical Shape Form | Rectangular, Fins | |
| Linear Length Dimension | 1.189" (30.20mm) | |
| Horizontal Width Dimension | 1.000" (25.40mm) | |
| Circular Measurement | - | |
| Heat Sink Fin Elevation | 0.311" (7.90mm) | |
| Power at Temp Increase | - | |
| Thermal Resistance with Fan | - | |
| Passive Cooling Resistance | 18.00°C/W | |
| Construction Material Type | Aluminum | |
| Surface Material Treatment | Black Anodized |
Description
Secured using a Bolt On approach for stable positioning. Has fin height recorded at 0.311" (7.90mm). Total length 1.189" (30.20mm) for size reference. Material type Aluminum for reliability and performance. Finish Black Anodized for both protection and visual appeal. Enclosure Bulk for component protection or transport. Thermal management package SOT-32, TO-220 for cooling purposes. Product condition Active for availability and lifecycle. Form Rectangular, Fins for device or component. Thermal resistance during natural convection 18.00°C/W for heat release. Category Board Level for classification or specification. Horizontal dimension width 1.000" (25.40mm).
