HN1D02FU(T5L,F,T)
Data Sheet
Attribute
Description
Manufacturer Part Number
HN1D02FU(T5L,F,T)
Manufacturer
Description
SWITCHING DIODE 80V CC 6 US6
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Diode Setup | 2 Pair Common Cathode | |
| Semiconductor Diode Category | Standard | |
| Reverse DC Voltage(Vr) (Max) | 80V | |
| Average DC Output Current | 100mA | |
| Forward Voltage (Vf) | 1.2V @ 100mA | |
| Operational Speed Rating | Small Signal =< 200mA (Io), Any Speed | |
| trr Recovery | 4ns | |
| Leakage at Vr | 500nA @ 80V | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | SOT-563, SOT-666 |
Description
Measures resistance at forward current 1.2V @ 100mA for LED or diode evaluation. Delivers average rectified current (Io) recorded at 100mA. Utilizes diode arrangement recognized as 2 Pair Common Cathode. Includes diode type indicated as Standard. Mounting style Surface Mount for structural integrity. Enclosure/case SOT-563, SOT-666 providing mechanical and thermal shielding. Reverse leakage current at Vr 500nA @ 80V for diode parameters. Reverse recovery duration 4ns for switching diodes. Velocity Small Signal =< 200mA (Io), Any Speed for mechanical or data efficiency. Peak Vce(on) at Vge Standard for transistor parameters.
