161CNQ045
Data Sheet
Attribute
Description
Manufacturer Part Number
161CNQ045
Manufacturer
Description
Diodes Rectifiers - Arrays and Modules,
45V,
80A
Manufacturer Lead Time
45 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Diode Setup | 1 Pair Common Cathode | |
| Semiconductor Diode Category | Schottky | |
| Reverse DC Voltage(Vr) (Max) | 45V | |
| Average DC Output Current | 80A | |
| Forward Voltage (Vf) | 710mV @ 80A | |
| Operational Speed Rating | Fast Recovery =< 500ns, > 200mA (Io) | |
| trr Recovery | - | |
| Leakage at Vr | 5mA @ 45V | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | TO-249AA (Modified), D-60 |
Description
Measures resistance at forward current 710mV @ 80A for LED or diode evaluation. Delivers average rectified current (Io) recorded at 80A. Utilizes diode arrangement recognized as 1 Pair Common Cathode. Includes diode type indicated as Schottky. Mounting style Chassis Mount for structural integrity. Enclosure/case TO-249AA (Modified), D-60 providing mechanical and thermal shielding. Reverse leakage current at Vr 5mA @ 45V for diode parameters. Velocity Fast Recovery =< 500ns, > 200mA (Io) for mechanical or data efficiency. Peak Vce(on) at Vge Schottky for transistor parameters.
