Attribute
Description
Manufacturer Part Number
ST13003-K
Manufacturer
Description
Transistors - Bipolar (BJT) -Single & Arrays,
NPN,
1.5A,...
Note :
GST will not be applied to orders shipping outside of India
Stock: 50000
Distributor: 145
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1455 | ₹ 18.38 | ₹ 26,742.90 |
| 1090 | ₹ 20.50 | ₹ 22,345.00 |
| 840 | ₹ 21.21 | ₹ 17,816.40 |
| 610 | ₹ 21.91 | ₹ 13,365.10 |
| 395 | ₹ 22.62 | ₹ 8,934.90 |
| 165 | ₹ 27.56 | ₹ 4,547.40 |
Stock: 2671
Distributor: 142
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 94.34 | ₹ 94.34 |
| 10 | ₹ 61.41 | ₹ 614.10 |
| 100 | ₹ 40.94 | ₹ 4,094.00 |
| 500 | ₹ 32.04 | ₹ 16,020.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Transistor Class | NPN | |
| Maximum Collector Amps | 1.5A | |
| Max Collector-Emitter Breakdown | 400V | |
| Vce Saturation (Max) @ Ib, Ic | 1.5V @ 500mA, 1.5A | |
| Collector Cutoff Max | 1mA | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 5 @ 1A, 2V | |
| Maximum Power Handling | 40W | |
| Transition Freq | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | TO-225AA, TO-126-3 |
Description
Measures resistance at forward current 1mA for LED or diode evaluation. Provides a maximum collector current (Ic) of 1.5A. Offers a collector cutoff current rated at 1mA. Features a DC current gain hFE at Ic evaluated at 1.5V @ 500mA, 1.5A. Mounting style Through Hole for structural integrity. Enclosure/case TO-225AA, TO-126-3 providing mechanical and thermal shielding. Peak power 40W for device protection. Type of transistor NPN for circuit architecture. Peak Vce(on) at Vge 1.5V @ 500mA, 1.5A for transistor parameters. Highest collector-emitter breakdown voltage 400V.
