BZT52C3V9-E3-08
Data Sheet
Attribute
Description
Manufacturer Part Number
BZT52C3V9-E3-08
Manufacturer
Description
Zener Diodes,
3.9V
Note :
GST will not be applied to orders shipping outside of India
Stock: 10675
Distributor: 117
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 21000 | ₹ 2.23 | ₹ 46,830.00 |
| 15000 | ₹ 2.27 | ₹ 34,050.00 |
| 9000 | ₹ 2.31 | ₹ 20,790.00 |
| 6000 | ₹ 3.20 | ₹ 19,200.00 |
| 3000 | ₹ 3.47 | ₹ 10,410.00 |
| 100 | ₹ 4.09 | ₹ 409.00 |
| 10 | ₹ 8.01 | ₹ 80.10 |
| 1 | ₹ 9.79 | ₹ 9.79 |
Stock: 15000
Distributor: 113
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 3000 | ₹ 2.50 | ₹ 7,500.00 |
| 9000 | ₹ 2.44 | ₹ 21,960.00 |
| 15000 | ₹ 2.42 | ₹ 36,300.00 |
| 45000 | ₹ 2.36 | ₹ 1,06,200.00 |
| 75000 | ₹ 2.31 | ₹ 1,73,250.00 |
Stock: 8197
Distributor: 110
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 259000 | ₹ 3.27 | ₹ 8,46,930.00 |
| 84000 | ₹ 3.38 | ₹ 2,83,920.00 |
| 33000 | ₹ 3.49 | ₹ 1,15,170.00 |
| 8000 | ₹ 3.60 | ₹ 28,800.00 |
| 2000 | ₹ 3.83 | ₹ 7,660.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Voltage - Zener (Vz) | 3.9V | |
| Accuracy Tolerance Percentage | ±5% | |
| Maximum Power Handling | 410mW | |
| Maximum Zener Impedance | 95 Ohm | |
| Reverse Leakage Vr | - | |
| Max Vf at If | - | |
| Ambient Temp Range | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | SOD-123 |
Description
Maximum Zzt impedance of 95 Ohm guarantees circuit stability. Mounting style Surface Mount for structural integrity. Enclosure/case SOD-123 providing mechanical and thermal shielding. Peak power 410mW for device protection. Tolerance ±5% for precision in manufacturing. Zener voltage Vz 3.9V for safeguarding.
