Attribute
Description
Manufacturer Part Number
MBRH12040R
Manufacturer
Description
Diodes Rectifiers - Arrays and Modules,
40V,
120A (DC)
Note :
GST will not be applied to orders shipping outside of India
Stock: 8
Distributor: 121
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 3,118.73 | ₹ 3,118.73 |
| 5 | ₹ 3,055.88 | ₹ 15,279.40 |
Stock: 44
Distributor: 117
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 50 | ₹ 4,524.73 | ₹ 2,26,236.50 |
| 25 | ₹ 4,741.93 | ₹ 1,18,548.25 |
| 10 | ₹ 5,045.03 | ₹ 50,450.30 |
| 1 | ₹ 5,895.45 | ₹ 5,895.45 |
Stock: 72
Distributor: 47
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 72 | ₹ 5,239.43 | ₹ 3,77,238.96 |
| 36 | ₹ 5,480.62 | ₹ 1,97,302.32 |
| 18 | ₹ 5,745.84 | ₹ 1,03,425.12 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Diode Setup | - | |
| Semiconductor Diode Category | Schottky, Reverse Polarity | |
| Reverse DC Voltage(Vr) (Max) | 40V | |
| Average DC Output Current | 120A (DC) | |
| Forward Voltage (Vf) | 650mV @ 120A | |
| Operational Speed Rating | Fast Recovery =< 500ns, > 200mA (Io) | |
| trr Recovery | - | |
| Leakage at Vr | 4mA @ 20V | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | D-67 |
Description
Measures resistance at forward current 650mV @ 120A for LED or diode evaluation. Delivers average rectified current (Io) recorded at 120A (DC). Includes diode type indicated as Schottky, Reverse Polarity. Mounting style Chassis Mount for structural integrity. Enclosure/case D-67 providing mechanical and thermal shielding. Reverse leakage current at Vr 4mA @ 20V for diode parameters. Velocity Fast Recovery =< 500ns, > 200mA (Io) for mechanical or data efficiency. Peak Vce(on) at Vge Schottky, Reverse Polarity for transistor parameters.
