Data Sheet
Attribute
Description
Manufacturer Part Number
CD1206-S01575
Manufacturer
Description
Diodes Rectifiers - Single,
100V,
150mA
Manufacturer Lead Time
18 weeks
Note :
GST will not be applied to orders shipping outside of India
Stock:
Distributor: 1
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 1.98 | ₹ 1.98 |
Stock:
Distributor: 3
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 6.41 | ₹ 6.41 |
| 10 | ₹ 3.65 | ₹ 36.50 |
| 100 | ₹ 2.76 | ₹ 276.00 |
| 1000 | ₹ 2.49 | ₹ 2,490.00 |
| 2500 | ₹ 2.14 | ₹ 5,350.00 |
Stock:
Distributor: 2
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 13.35 | ₹ 13.35 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Diode Type | Standard | |
| Reverse DC Voltage(Vr) | 100V | |
| Current - Average Rectified (Io) | 150mA | |
| Forward Voltage (Vf) | 1V @ 50mA | |
| Speed | Small Signal =< 200mA (Io), Any Speed | |
| Reverse Recovery Time (trr) | 4ns | |
| Reverse Leakage Current @ Vr | 2.5µA @ 100V | |
| Capacitance @ Vr, F | 3pF @ 0V, 100MHz | |
| Thermal Resistance | - | |
| Operating Temperature - Junction | -55°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 1206 (3216 Metric) |
