Data Sheet
Attribute
Description
Manufacturer Part Number
1N3214
Manufacturer
Description
Diodes Rectifiers - Single,
600V,
15A
Manufacturer Lead Time
10 weeks
Note :
GST will not be applied to orders shipping outside of India
Stock:
Distributor: 1
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 270.56 | ₹ 270.56 |
Stock:
Distributor: 3
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 372.91 | ₹ 372.91 |
| 25 | ₹ 363.12 | ₹ 9,078.00 |
| 100 | ₹ 324.85 | ₹ 32,485.00 |
| 250 | ₹ 290.14 | ₹ 72,535.00 |
| 500 | ₹ 252.76 | ₹ 1,26,380.00 |
| 1000 | ₹ 243.86 | ₹ 2,43,860.00 |
Stock:
Distributor: 2
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 483.27 | ₹ 483.27 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Diode Type | Standard | |
| Reverse DC Voltage(Vr) | 600V | |
| Current - Average Rectified (Io) | 15A | |
| Forward Voltage (Vf) | 1.5V @ 15A | |
| Speed | Standard Recovery >500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Reverse Leakage Current @ Vr | 10µA @ 50V | |
| Capacitance @ Vr, F | - | |
| Thermal Resistance | 0.65°C/W Jc | |
| Operating Temperature - Junction | -65°C ~ 175°C | |
| Mounting Type | Chassis, Stud Mount | |
| Package / Case | DO-203AB, DO-5, Stud |
