Data Sheet
Attribute
Description
Manufacturer Part Number
DL4148-TP
Manufacturer
Description
SWITCHING DIODE,
100V,
MiniMELF; Diode T; SWITCHING DIODE,...
Manufacturer Lead Time
18 weeks
Note :
GST will not be applied to orders shipping outside of India
Stock:
Distributor: 3
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 2.85 | ₹ 2.85 |
| 2500 | ₹ 2.67 | ₹ 6,675.00 |
| 5000 | ₹ 2.40 | ₹ 12,000.00 |
| 7500 | ₹ 2.14 | ₹ 16,050.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Diode Type | Standard | |
| Reverse DC Voltage(Vr) | 75V | |
| Current - Average Rectified (Io) | 150mA | |
| Forward Voltage (Vf) | 1V @ 10mA | |
| Speed | Small Signal =< 200mA (Io), Any Speed | |
| Reverse Recovery Time (trr) | 4ns | |
| Reverse Leakage Current @ Vr | 5µA @ 75V | |
| Capacitance @ Vr, F | - | |
| Thermal Resistance | 500°C/W Ja | |
| Operating Temperature - Junction | 175°C (Max) | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-213AC |
