JANTX2N6804
Data Sheet
Attribute
Description
Manufacturer Part Number
JANTX2N6804
Manufacturer
Description
MOSFET P-CH 100V 11A TO-204AA
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Field Effect Transistor Type | MOSFET P-Channel, Metal Oxide | |
| Drain-Source Breakdown Volts | 100V | |
| Continuous Drain Current at 25C | 11A (Tc) | |
| Max On-State Resistance | 360 mOhm @ 11A, 10V | |
| Max Threshold Gate Voltage | 4V @ 250µA | |
| Gate Charge at Vgs | 29nC @ 10V | |
| Input Cap at Vds | - | |
| Maximum Power Handling | 75W | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | TO-204AA, TO-3 |
Description
Measures resistance at forward current MOSFET P-Channel, Metal Oxide for LED or diode evaluation. Supports a continuous drain current (Id) of 11A (Tc) at 25°C. Supports Vdss drain-to-source voltage rated at 100V. Accommodates FET classification identified as MOSFET P-Channel, Metal Oxide. Upholds 29nC @ 10V gate charge at Vgs for reliable MOSFET functionality. Mounting style Through Hole for structural integrity. Enclosure/case TO-204AA, TO-3 providing mechanical and thermal shielding. Peak power 75W for device protection. Peak Rds(on) at Id 29nC @ 10V for MOSFET efficiency. Peak Rds(on) at Id and Vgs 360 mOhm @ 11A, 10V for MOSFET criteria. Peak Vgs(th) at Id 4V @ 250µA for MOSFET threshold level.
