Data Sheet
Attribute
Description
Manufacturer Part Number
CM200DY-12NF
Manufacturer
Description
IGBTs - Arrays,
Modules,
600V,
200A,
650W
Manufacturer Lead Time
Not specified
Note :
GST will not be applied to orders shipping outside of India
Stock:
Distributor: 3
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 10,670.21 | ₹ 10,670.21 |
| 10 | ₹ 10,024.07 | ₹ 1,00,240.70 |
| 100 | ₹ 8,989.00 | ₹ 8,98,900.00 |
| 250 | ₹ 8,665.93 | ₹ 21,66,482.50 |
| 500 | ₹ 8,536.88 | ₹ 42,68,440.00 |
| 1000 | ₹ 8,148.84 | ₹ 81,48,840.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| IGBT Type | - | |
| Voltage - Collector Emitter Breakdown (Max) | 600V | |
| Current - Collector (Ic) (Max) | 200A | |
| Power - Max | 650W | |
| Vce(on) (Max) @ Vge, Ic | 2.2V @ 15V, 200A | |
| Input Type | 30nF @ 10V | |
| Mounting Type | Chassis Mount | |
| Package / Case | Module |
