RJP6085DPN-00#T2
Data Sheet
Attribute
Description
Manufacturer Part Number
RJP6085DPN-00#T2
Manufacturer
Description
IGBTs - Single,
600V,
40A,
178.5W
Manufacturer Lead Time
19 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| IGBT Class | - | |
| Max Collector-Emitter Breakdown | 600V | |
| Maximum Collector Amps | 40A | |
| Maximum Power Handling | 178.5W | |
| Vce(on) (Max) @ Vge, Ic | 3.5V @ 15V, 40A | |
| Entry Signal Category | Standard | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | TO-220-3 |
Description
Provides a maximum collector current (Ic) of 40A. Features a DC current gain hFE at Ic evaluated at 3.5V @ 15V, 40A. Set up with Standard input type for versatile applications. Mounting style Through Hole for structural integrity. Enclosure/case TO-220-3 providing mechanical and thermal shielding. Peak power 178.5W for device protection. Peak Vce(on) at Vge 3.5V @ 15V, 40A for transistor parameters. Highest collector-emitter breakdown voltage 600V.
