JANTX2N5682
Data Sheet
Attribute
Description
Manufacturer Part Number
JANTX2N5682
Manufacturer
Description
Transistors - Bipolar (BJT) -Single & Arrays,
NPN,
1A,
120V
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Transistor Class | NPN | |
| Maximum Collector Amps | 1A | |
| Max Collector-Emitter Breakdown | 120V | |
| Vce Saturation (Max) @ Ib, Ic | 1V @ 50mA, 500mA | |
| Collector Cutoff Max | 10µA | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 40 @ 250mA, 2V | |
| Maximum Power Handling | 1W | |
| Transition Freq | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | TO-205AD, TO-39-3 Metal Can |
Description
Measures resistance at forward current 10µA for LED or diode evaluation. Provides a maximum collector current (Ic) of 1A. Offers a collector cutoff current rated at 10µA. Features a DC current gain hFE at Ic evaluated at 1V @ 50mA, 500mA. Mounting style Through Hole for structural integrity. Enclosure/case TO-205AD, TO-39-3 Metal Can providing mechanical and thermal shielding. Peak power 1W for device protection. Type of transistor NPN for circuit architecture. Peak Vce(on) at Vge 1V @ 50mA, 500mA for transistor parameters. Highest collector-emitter breakdown voltage 120V.
