Attribute
Description
Manufacturer Part Number
SA5209D,602
Manufacturer
Description
Linear - Amplifiers - Instrumentation,
OP Amps,...
Manufacturer Lead Time
52 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Signal Booster Category | Variable Gain | |
| Electrical Circuit Count | 1 | |
| Exit Signal Category | Differential | |
| Voltage Slew Speed V/us | - | |
| Amplifier Bandwidth Gain | - | |
| 3dB Bandwidth | - | |
| Bias Input Amperage | 700nA | |
| Input Offset Voltage | - | |
| Power Supply Amperage | 43mA | |
| Per-Channel Output Current | - | |
| Single or Dual Supply Option | 4.5 V ~ 7 V | |
| Ambient Temp Range | -40?C ~ 85?C | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 16-SOIC (0.154", 3.90mm Width) |
Description
Incorporates a Variable Gain amplifier design for improved signal transmission. Includes input bias current rated at 700nA. Utilizes supply current defined as 43mA. Mounting style Surface Mount for structural integrity. Total circuits 1 for electrical or electronic designs. Operating temperature -40?C ~ 85?C for thermal stability. Output type Differential for system compatibility. Enclosure/case 16-SOIC (0.154", 3.90mm Width) providing mechanical and thermal shielding. Peak Vce(on) at Vge 1 for transistor parameters. Single/dual voltage supply ± 4.5 V ~ 7 V for various devices.
