IXSN55N120A
Data Sheet
Attribute
Description
Manufacturer Part Number
IXSN55N120A
Manufacturer
Description
IGBTs - Arrays,
Modules,
1200V,
110A,
500W
Manufacturer Lead Time
38 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| IGBT Class | - | |
| Max Collector-Emitter Breakdown | 1200V | |
| Maximum Collector Amps | 110A | |
| Maximum Power Handling | 500W | |
| Vce(on) (Max) @ Vge, Ic | 4V @ 15V, 55A | |
| Entry Signal Category | 8nF @ 25V | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | SOT-227-4, miniBLOC |
Description
Provides a maximum collector current (Ic) of 110A. Features a DC current gain hFE at Ic evaluated at 4V @ 15V, 55A. Set up with 8nF @ 25V input type for versatile applications. Mounting style Chassis Mount for structural integrity. Enclosure/case SOT-227-4, miniBLOC providing mechanical and thermal shielding. Peak power 500W for device protection. Peak Vce(on) at Vge 4V @ 15V, 55A for transistor parameters. Highest collector-emitter breakdown voltage 1200V.
