APTGT50TA170PG
Data Sheet
Attribute
Description
Manufacturer Part Number
APTGT50TA170PG
Manufacturer
Description
IGBTs - Arrays,
Modules,
1700V,
70A,
310W
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| IGBT Class | Trench and Field Stop | |
| Max Collector-Emitter Breakdown | 1700V | |
| Maximum Collector Amps | 70A | |
| Maximum Power Handling | 310W | |
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 50A | |
| Entry Signal Category | 4.4nF @ 25V | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | SP6 |
Description
Provides a maximum collector current (Ic) of 70A. Features a DC current gain hFE at Ic evaluated at 2.4V @ 15V, 50A. Designed as Trench and Field Stop IGBT type for effective power switching. Set up with 4.4nF @ 25V input type for versatile applications. Mounting style Chassis Mount for structural integrity. Enclosure/case SP6 providing mechanical and thermal shielding. Peak power 310W for device protection. Peak Vce(on) at Vge 2.4V @ 15V, 50A for transistor parameters. Highest collector-emitter breakdown voltage 1700V.
