CM600HU-12F
Data Sheet
Attribute
Description
Manufacturer Part Number
CM600HU-12F
Manufacturer
Description
IGBTs - Arrays,
Modules,
600V,
600A,
1420W
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| IGBT Class | Trench | |
| Max Collector-Emitter Breakdown | 600V | |
| Maximum Collector Amps | 600A | |
| Maximum Power Handling | 1420W | |
| Vce(on) (Max) @ Vge, Ic | 2.2V @ 15V, 600A | |
| Entry Signal Category | 160nF @ 10V | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | Module |
Description
Provides a maximum collector current (Ic) of 600A. Features a DC current gain hFE at Ic evaluated at 2.2V @ 15V, 600A. Designed as Trench IGBT type for effective power switching. Set up with 160nF @ 10V input type for versatile applications. Mounting style Chassis Mount for structural integrity. Enclosure/case Module providing mechanical and thermal shielding. Peak power 1420W for device protection. Peak Vce(on) at Vge 2.2V @ 15V, 600A for transistor parameters. Highest collector-emitter breakdown voltage 600V.
