NX3225DA-16.000MHZ-EXS00A-03311
Data Sheet
Attribute
Description
Manufacturer Part Number
NX3225DA-16.000MHZ-EXS00A-03311
Manufacturer
Description
Crystals,
16MHz,
7.2pF,
Surface Mount
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Oscillation Rate Hz | 16MHz | |
| Oscillator Drift Tolerance | - | |
| Hz Deviation Limit | ±10ppm | |
| Output Load Cap Value | 7.2pF | |
| ESR Value | - | |
| Op Temp Range | -10°C ~ 70°C | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 4-SMD, No Lead (DFN, LCC) | |
| Package Size Specs | - | |
| Vertical Dimension | - |
Description
Operates at a frequency of 16MHz. Upholds ±10ppm frequency tolerance for precise electronic functionality. Load capacitance 7.2pF to ensure stable electrical operation. Mounting style Surface Mount for structural integrity. Operating temperature range -10°C ~ 70°C for environmental resilience. Enclosure/case 4-SMD, No Lead (DFN, LCC) providing mechanical and thermal shielding.
