JD7509N
Data Sheet
Attribute
Description
Manufacturer Part Number
JD7509N
Manufacturer
Description
SWITCHLOCK SP 2POS SLD LUG 125V
Manufacturer Lead Time
26 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Switch Position Options | 2 | |
| Pin Voltage Tolerance | 4A @ 125VAC | |
| Activator Mechanism Type | Flat Key | |
| Attachment Mounting Style | Panel Mount | |
| Lead Termination Type | Solder Lug | |
| Key Extraction Slots | 1 only | |
| Switch Throw Angle | 90° |
Description
Fitted with a Flat Key actuator type to execute the intended function. Offers a throw angle of 90° for effective switching action. Delivers contact rating at voltage specified as 4A @ 125VAC. Accommodates 1 only removable key positions for versatile operation. Mounting style Panel Mount for structural integrity. Total positions 2 for switches or mechanical elements. Termination type Solder Lug for connector or device.
