Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Electrical Pathway | SPDT | |
| Switch Operation Mode | On-Mom | |
| Rated Current | 20A (AC), 500mA (DC) | |
| AC Voltage Max | 125V | |
| DC Voltage Max | 125V | |
| Activator Mechanism Type | Overtravel Plunger | |
| Attachment Mounting Style | Panel Mount | |
| Lead Termination Type | Screw Terminal | |
| Dust Water Resistance Rating | IP65 - Dust Tight, Water Resistant | |
| Operating Force, Torque | 368gf | |
| Detachment Pressure | 113gf | |
| Initial Travel Distance | 0.020 (0.5mm) | |
| Switch Travel Difference | - | |
| Excess Travel Distance | 0.219 (5.6mm) |
Description
Fitted with a Overtravel Plunger actuator type to execute the intended function. Measures resistance at forward current 368gf for LED or diode evaluation. Set up to circuit type characterized as SPDT. Provides a current rating of 20A (AC), 500mA (DC). Rated with IP IP65 - Dust Tight, Water Resistant for protection against dust and moisture ingress. Mounting style Panel Mount for structural integrity. Excess travel 0.219 (5.6mm) for mechanical safety and longevity. Initial movement 0.020 (0.5mm) for switch or mechanical control. Force required 113gf for mechanical or switch operation. Operation mode switch On-Mom for electrical function. Termination type Screw Terminal for connector or device. Peak Vce(on) at Vge SPDT for transistor parameters. Maximum AC voltage rating 125V for device specifications. Maximum DC voltage rating 125V for components.
