2649LH/2A200000L0
Data Sheet
Attribute
Description
Manufacturer Part Number
2649LH/2A200000L0
Manufacturer
Description
SWITCH ROCKER DPDT 10A 125V
Manufacturer Lead Time
26 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Electrical Pathway | DPDT | |
| Switch Operation Mode | On-Off-On | |
| Rated Current | 10A (AC), 8A (DC) | |
| AC Voltage Max | 125V | |
| DC Voltage Max | 24V | |
| Actuator Design | Actuator Arm, Cap Required | |
| Activator Cap Shade | - | |
| Activator Label Indicator | Varies by Cap | |
| LED Illumination Shades | - | |
| Standard Illumination Volts | - | |
| Attachment Mounting Style | Panel Mount, Snap-In | |
| Lead Termination Type | Quick Connect - 0.250" (6.3mm) | |
| Dust Water Resistance Rating | - | |
| Mount Cutout Specs | Rectangular - 30.00mm x 22.00mm |
Description
Includes labels marked as Varies by Cap for straightforward identification. Utilizes a Actuator Arm, Cap Required actuator type tailored for application requirements. Set up to circuit type characterized as DPDT. Provides a current rating of 10A (AC), 8A (DC). Mounting style Panel Mount, Snap-In for structural integrity. Cutout dimensions Rectangular - 30.00mm x 22.00mm for precise mounting. Operation mode switch On-Off-On for electrical function. Termination type Quick Connect - 0.250" (6.3mm) for connector or device. Peak Vce(on) at Vge DPDT for transistor parameters. Maximum AC voltage rating 125V for device specifications. Maximum DC voltage rating 24V for components.
