Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Electrical Pathway | SPST | |
| Switch Operation Mode | On-Off | |
| Rated Current | 10A (AC) | |
| AC Voltage Max | 125V | |
| DC Voltage Max | 30V | |
| Actuator Design | Concave (Curved) | |
| Activator Cap Shade | Black | |
| Activator Label Indicator | No Marking | |
| LED Illumination Shades | - | |
| Standard Illumination Volts | - | |
| Attachment Mounting Style | Panel Mount, Snap-In | |
| Lead Termination Type | Solder, Quick Connect - 0.110" (2.8mm) | |
| Dust Water Resistance Rating | Dust Proof | |
| Mount Cutout Specs | Rectangular - 24.00mm x 15.40mm |
Description
Includes labels marked as No Marking for straightforward identification. Utilizes a Concave (Curved) actuator type tailored for application requirements. Set up to circuit type characterized as SPST. Crafted with actuator or cap color indicated as Black for visual distinction. Provides a current rating of 10A (AC). Rated with IP Dust Proof for protection against dust and moisture ingress. Mounting style Panel Mount, Snap-In for structural integrity. Cutout dimensions Rectangular - 24.00mm x 15.40mm for precise mounting. Operation mode switch On-Off for electrical function. Termination type Solder, Quick Connect - 0.110" (2.8mm) for connector or device. Peak Vce(on) at Vge SPST for transistor parameters. Maximum AC voltage rating 125V for device specifications. Maximum DC voltage rating 30V for components.
