Data Sheet
Attribute
Description
Manufacturer Part Number
B3W-9000-RG2N
Manufacturer
Description
Tactile switch
Manufacturer Lead Time
Not specified
Note :
GST will not be applied to orders shipping outside of India
Stock:
Distributor: 11
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 230.51 | ₹ 230.51 |
| 5 | ₹ 217.16 | ₹ 1,085.80 |
| 20 | ₹ 202.92 | ₹ 4,058.40 |
| 100 | ₹ 189.57 | ₹ 18,957.00 |
| 500 | ₹ 176.22 | ₹ 88,110.00 |
Stock:
Distributor: 2
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 337.31 | ₹ 337.31 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Circuit | SPST-NO | |
| Switch Function | Off-Mom | |
| Contact Rating @ Voltage | 0.05A @ 24VDC | |
| Actuator Type | Square Button | |
| Mounting Type | Through Hole | |
| Actuator Height off PCB, from Pins | 10.20mm | |
| Actuator Orientation | Top Actuated | |
| Termination Style | PC Pin | |
| Outline | 10.00mm x 10.00mm | |
| Illumination | Illuminated | |
| Illumination Voltage (Nominal) | 1.8, 2.1 VDC | |
| Illumination Type, Color | LED, Red/Green | |
| Operating Force | 160gf | |
| Ingress Protection | - |
