Data Sheet
Attribute
Description
Manufacturer Part Number
AD8601ARTZ-REEL7
Manufacturer
Description
Operational amplifier
Manufacturer Lead Time
12 weeks
Note :
GST will not be applied to orders shipping outside of India
Stock:
Distributor: 3
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 59.27 | ₹ 59.27 |
| 3000 | ₹ 59.27 | ₹ 1,77,810.00 |
| 6000 | ₹ 58.74 | ₹ 3,52,440.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Amplifier Type | General Purpose | |
| Number of Circuits | 1 | |
| Output Type | Rail-to-Rail | |
| Slew Rate | 6 V/?s | |
| Gain Bandwidth Product | 8.4MHz | |
| -3db Bandwidth | - | |
| Current - Input Bias | 0.2pA | |
| Voltage - Input Offset | 80?V | |
| Current - Supply | 750?A | |
| Current - Output / Channel | 50mA | |
| Voltage - Supply, Single/Dual (±) | 2.7 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | SC-74A, SOT-753 |
