Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 26M | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Device Type Classification | Permanent Magnet | |
| Electromagnetic Coil Design | Unipolar | |
| Rated Operating Voltage | 12VDC | |
| Ampere Capacity Rating | 110 mA | |
| Revolution Step Count | 48.0 | |
| Stepper Motor Step Degrees | 7.5° | |
| Precision Level | ±15% | |
| Holding Torque Rating | 1.3 / 9.2 | |
| Package Size Specs | Round - 1.030" Dia (26.16mm) | |
| Motor Frame Standard | - | |
| Shaft Rod Width | 0.079" (2.00mm) | |
| Shaft Bearing Total Length | 0.445" (11.30mm) | |
| Screw Hole Pitch | 1.370" (34.90mm) | |
| Lead Termination Type | Wire Leads | |
| Ambient Temp Range | -20°C ~ 70°C | |
| Inductor Resistance Value | 110 Ohms | |
| Key Product Highlights | Round Shaft |
Description
Delivers measurement accuracy rated at ±15% for trustworthy outcomes. Has coil resistance recorded at 110 Ohms for reliable electromagnetic functionality. Built with a coil type designated as Unipolar for effective electrical performance. Defines current rating in amps as 110 mA. Features shaft diameter indicated as 0.079" (2.00mm). Furnished with features classified as Round Shaft. Combined length of shaft and bearing 0.445" (11.30mm) for seamless assembly. Mounting hole spacing 1.370" (34.90mm) for precise alignment. Operating temperature -20°C ~ 70°C for thermal stability. Enclosure Bulk for component protection or transport. Product condition Active for availability and lifecycle. Product or component classification series 26M. Dimensions Round - 1.030" Dia (26.16mm) for mechanical or electrical components. Dimension measurement Round - 1.030" Dia (26.16mm) for component details. Step angle 7.5° applicable to stepper motors. Steps per revolution 48.0 for rotating devices. Termination type Wire Leads for connector or device. Retention torque 1.3 / 9.2 in oz-in/mNm for holding. Category Permanent Magnet for classification or specification. Operating voltage rating 12VDC for device specifications.
