TY-146P

Description

Includes primary DCR recorded at 17Ohm, 19Ohm. Offers secondary DCR specified as 14.5Ohm, 22Ohm. Provides a 200Hz ~ 15kHz frequency range for wide-spectrum applications. Delivers ±2dB frequency response for reliable signal fidelity. Maximum seated height of 1.187" (30.15mm) for components mounted on the board. Primary impedance specified at 600, 150/150 Ohms for electrical design purposes. Secondary impedance set at 600, 150/150 Ohms for optimal load matching. Provides 1.5dB insertion loss for reduced signal attenuation. Mounting style Through Hole for structural integrity. Operating temperature -20°C ~ 85°C for thermal stability. Enclosure Bulk for component protection or transport. Signal power level 1W for operational standards. Product condition Active for availability and lifecycle. Signal return loss 26dB for quality and reflection. Product or component classification series TY. Dimensions 1.375" L x 1.187" W (34.93mm x 30.15mm) for mechanical or electrical components. Dimension measurement 1.375" L x 1.187" W (34.93mm x 30.15mm) for component details. Termination type PC Pin for connector or device. Type of transformer Data/Voice Coupling for electrical conversion. Turns ratio from primary to secondary 1:1 for transformers. Isolation voltage 1500V for electrical protection.
